StarTech 4-Port SuperSpeed USB 3.0 PCIe Card with SATA Power Connector & UASP

The 4-Port SuperSpeed USB 3.0 PCIe Card with SATA Power Connector & UASP from StarTech adds 4 external USB 3.0 ports to any PCIe-enabled computer system with support for data rates up to 5 Gb/s. The card uses a "stacked" port layout that places the ports one on top of the other, enabling all four USB 3.0 ports to be external facing, while still allowing the card to fit into a small form factor/low-profile computer system using the included low-profile bracket. Additionally, with a built-in SATA power connector, each USB port can provide up to 900mA of power to devices that draw power from a host bus connection (500mA for USB 2.0) by connecting to your computer's power supply.

Enhanced with UASP support (USB Attached SCSI Protocol), this USB 3.0 controller performs up to 70% faster than conventional USB 3.0 when paired with a UASP supported enclosure. Using a more efficient protocol than the traditional USB BOT (Bulk-Only Transport), UASP technology optimizes transfers by allowing multiple commands to be processed simultaneously, significantly increasing transfer speeds with less wait time on data transfers. UASP is supported in Windows 8, Server 2012, and Linux kernel 2.6.3 or later.

Note:

_UASP require a compatible operating system._

The USB 3.0 PCIe card features 4 external USB 3.0 ports using a space-saving stacked layout

Provides quick file transfers and performs up to 70% faster than traditional USB 3.0 when used with a UASP-supported enclosure

Power high-powered USB devices as necessary, with the built-in optional SATA power connector

UASP support for more efficient data transfer

Fully compliant with USB 3.0 revision 1.0 specifications and Intel xHCI rev0.95 specifications

Optionally provides up to 900mA per USB port

Backwards compatible with USB 2.0 and USB 1.0/1.1 devices

Compliant with PCIe 2.0 specifications

Includes a low-profile/half-height installation bracket

Upgrade an older PCIe-based system with USB 3.0 connectivity to fully utilize USB 3.0 devices

Expand a system's USB capabilities by adding four additional external USB ports for connecting additional external hard drives, CD/DVD drives, MP3 players, printers, scanners, webcams, game controllers, digital cameras, and more
