Smart-AVI V2V-HDAV HDMI to Composite RCA Downscaler with HDMI Loop Output

The V2V-HDAV HDMI to Composite RCA Downscaler with HDMI Loop Output from Smart-AVI is designed to convert HD HDMI input signals to SD analog CVBS output. It downscales the 1080p HDMI input to standard NTSC (480i) or PAL (576i) formats. In addition, it converts digital audio to analog L/R stereo audio output.

The HDMI to composite downscaler offers a local HDMI loop that allows routing 1080p signal along with the downscaled signal, eliminating the use of an external splitter. This functionality makes routing 1080p signals effortless to a variety of older displays and audio receivers. Requiring no software driver, the V2V-HDAVS Downscaler offers plug-and-play capability.

Plug-and-play design that doesn't require a software driver

HDMI 1.3 compatible

Supports NTSC and PAL TV formats

HDMI input and output, AV output, and stereo audio output

HDMI Input: 480p, 576p, 720p, 1080i, 1080p @ 60Hz

Compatible DVI Modes: 800 x 600, 1024 x 768, 1280 x 720, 1280 x1024, 1920 x 1080 @ 60 Hz

Supports HDMI 1.3 and HDCP protocol

CVBS Output: 480i, 576i

Suitable for video conferencing, video capture, video walls, educational institutions, security systems, video modulation, multimedia presentations, and video installations

Designed and manufactured in USA
