OSEE GoStream Deck HDMI/USB Live Streaming Video Switcher Kit

The GoStream Deck HDMI/USB Live Streaming Video Switcher Kit from OSEE is an all-in-one portable streaming solution that includes a switcher unit, 14" monitor, and a hard case with integrated features. The switcher has four HDMI inputs and one USB-C input that interface with one HDMI output and two USB-C outputs. Both the input and output ports support up to 1080p60 video. An SD card slot allows for direct recording and playback to the included monitor without requiring a separate PC. Stream via RTMP and Ethernet connection to up to three social media platforms.

• The GoStream Deck's comprehensive control panel, built-in user interface, and SD card recording and playback function reduce the number of required devices needed to facilitate your livestream. This keeps your production low cost and efficient.
• Livestream to three different platforms simultaneously using the integrated Ethernet port on the GoStream. Connect a USB webcam to the USB-C input and output that feed via OBS, VMix, or Zoom using the USB-C output port.
• Additional ports on the switcher allow you to expand your setup to best suit your production. Connect up to five video input sources like cameras and UVC sources and output them to the included monitor or projector for simultaneous presentation.

Included in the kit is a 14" monitor with 1920 x 1080 resolution and 350 cd/m² brightness. Both the monitor and the deck are integrated into a hard case for easy on-the-go travel. The case has a built-in silent fan to ensure your devices remain cool during operation. Three cheese plates on the outside of the case with 1/4"-20 and 3/8"-16 threads allow you to then attach the case to a tripod and secure articulating arms or other accessories. The entire kit can be powered via AC in or DC in and even features a 5 VDC out to power select accessories.

An internal audio mixer supports seven channels of embedded and input audio sources, with four audio sources coming from the HDMI inputs, one from the AUX input, and two from dedicated 3.5mm TRS microphone ports. Mix the inputs into the program output using the On/Off or AFV controls on the switcher and adjust parameters like gain, balance, and fade. Monitor audio from a selected source using the headphone input.

Using the Super Source feature, merge two video windows and one background video into a unified single source. The source then becomes a standard video input integrated into the composition engine. Select source material from video inputs or internally generated still image signals. Modify the layout, size, position, and border of each window.

The GoStream supports six layers of special effects including Super Source, upstream keyers, downstream keyers, Chroma keyers, transitions, and a still image generator. Craft visually appealing, multi-layered effects tailored to your production. Use the eight Macro Memories to record specific composition functions and set them as custom presets for efficient recall.

UPC: 769293552220
